This tutorial covers the SQL library and its usage with Basic4android.
There are many general SQL tutorials that cover the actual SQL language. If you are not familiar with SQL it is recommended to start with such a tutorial.
SQL Introduction
A new code module is available named DBUtils. It contains methods for common tasks which you can use and also learn from the code.
Android uses SQLite which is an open source SQL implementation.
Each implementation has some nuances. The following two links cover important information regarding SQLite.
SQLite syntax:
Query Language Understood by SQLite
SQLite data types:
Datatypes In SQLite Version 3
SQL in Basic4android
The first step is to add a reference to the SQL library. This is done by going to the Libraries tab and checking SQL.
There are two types in this library.
An SQL object gives you access to the database.
The Cursor object allows you to process queries results.
Usually you will want to declare the SQL object as a process global object. This way it will be kept alive when the activity is recreated.
SQLite stores the database in a single file.
When we initialize the SQL object we pass the path to a database file (which can be created if needed).
Code:
Sub Process_Globals
Dim SQL1 As SQL
End Sub
Sub Globals
End Sub
Sub Activity_Create(FirstTime As Boolean)
If FirstTime Then
SQL1.Initialize(File.DirDefaultExternal, "test1.db", True)
End If
CreateTables
FillSimpleData
LogTable1
InsertManyRows
Log("Number of rows = " & SQL1.ExecQuerySingleResult("SELECT count(*) FROM table1"))
InsertBlob 'stores an image in the database.
ReadBlob 'load the image from the database and displays it.
End Sub
The SQL1 object will only be initialized once when the process starts.
In our case we are creating it in the sd card. The last parameter (CreateIfNecessary) is True so the file will be created if it doesn't exist.
There are three types of methods that execute SQL statements.
ExecNonQuery - Executes a "writing" statement and doesn't return any result. This can be for example: INSERT, UPDATE or CREATE TABLE.
ExecQuery - Executes a query statement and returns a Cursor object that is used to process the results.
ExecQuerySingleResult - Executes a query statement and returns the value of the first column in the first row in the result set. This method is a shorthand for using ExecQuery and reading the value with a Cursor.
We will analyze the example code:
Code:
Sub CreateTables
SQL1.ExecNonQuery("DROP TABLE IF EXISTS table1")
SQL1.ExecNonQuery("DROP TABLE IF EXISTS table2")
SQL1.ExecNonQuery("CREATE TABLE table1 (col1 TEXT , col2 INTEGER, col3 INTEGER)")
SQL1.ExecNonQuery("CREATE TABLE table2 (name TEXT, image BLOB)")
End Sub
The above code first deletes the two tables if they exist and then creates them again.
Code:
Sub FillSimpleData
SQL1.ExecNonQuery("INSERT INTO table1 VALUES('abc', 1, 2)")
SQL1.ExecNonQuery2("INSERT INTO table1 VALUES(?, ?, ?)", Array As Object("def", 3, 4))
End Sub
In this code we are adding two rows. SQL.ExecNonQuery2 receives two parameters. The first parameter is the statement which includes question marks. The question marks are then replaced with values from the second List parameter. The List can hold numbers, strings or arrays of bytes (blobs).
Arrays are implicitly converted to lists so instead of creating a list we are using the Array keyword to create an array of objects.
Code:
Sub LogTable1
Dim Cursor1 As Cursor
Cursor1 = SQL1.ExecQuery("SELECT col1, col2, col3 FROM table1")
For i = 0 To Cursor1.RowCount - 1
Cursor1.Position = i
Log("************************")
Log(Cursor1.GetString("col1"))
Log(Cursor1.GetInt("col2"))
Log(Cursor1.GetInt("col3"))
Next
Cursor1.Close
End Sub
This code uses a Cursor to log the two rows that were previously added.
SQL.ExecQuery returns a Cursor object.
Then we are using the For loop to iterate over all the results.
Note that before reading values from the Cursor we are first setting its position (the current row).
Code:
Sub InsertManyRows
SQL1.BeginTransaction
Try
For i = 1 To 500
SQL1.ExecNonQuery2("INSERT INTO table1 VALUES ('def', ?, ?)", Array As Object(i, i))
Next
SQL1.TransactionSuccessful
Catch
Log(LastException.Message)
End Try
SQL1.EndTransaction
End Sub
This code is an example of adding many rows. Internally a lock is acquired each time a "writing" operation is done.
By explicitly creating a transaction the lock is acquired once.
The above code took less than half a second to run on a real device.
Without the BeginTransaction / EndTransaction block it took about 70 seconds.
A transaction block can also be used to guarantee that a set of changes were successfully done. Either all changes are made or none are made.
By calling SQL.TransactionSuccessful we are marking this transaction as a successful transaction. If you omit this line, all the 500 INSERTS will be ignored.
It is very important to call EndTransaction eventually.
Therefore the transaction block should usually look like:
Code:
SQL1.BeginTransaction
Try
'Execute the sql statements.
SQL.TransactionSuccessful
Catch
'the transaction will be cancelled
End Try
SQL.EndTransaction
Note that using transactions is only relevant when doing "writing" operations.
Blobs
The last two methods write an image file to the database and then read it and set it as the activity background.
Code:
Sub InsertBlob
'convert the image file to a bytes array
Dim InputStream1 As InputStream
InputStream1 = File.OpenInput(File.DirAssets, "smiley.gif")
Dim OutputStream1 As OutputStream
OutputStream1.InitializeToBytesArray(1000)
File.Copy2(InputStream1, OutputStream1)
Dim Buffer() As Byte 'declares an empty array
Buffer = OutputStream1.ToBytesArray
'write the image to the database
SQL1.ExecNonQuery2("INSERT INTO table2 VALUES('smiley', ?)", Array As Object(Buffer))
End Sub
Here we are using a special type of OutputStream which writes to a dynamic bytes array.
File.Copy2 copies all available data from the input stream into the output stream.
Then the bytes array is written to the database.
Code:
Sub ReadBlob
Dim Cursor1 As Cursor
'Using ExecQuery2 is safer as it escapes special characters automatically.
'In this case it doesn't really matter.
Cursor1 = SQL1.ExecQuery2("SELECT image FROM table2 WHERE name = ?", Array As String("smiley"))
Cursor1.Position = 0
Dim Buffer() As Byte 'declare an empty byte array
Buffer = Cursor1.GetBlob("image")
Dim InputStream1 As InputStream
InputStream1.InitializeFromBytesArray(Buffer, 0, Buffer.Length)
Dim Bitmap1 As Bitmap
Bitmap1.Initialize2(InputStream1)
InputStream1.Close
Activity.SetBackgroundImage(Bitmap1)
End Sub
Using a Cursor.GetBlob we fetch the previously stored image.
Now we are using an input stream that reads from this array and load the image.
